CPU: Quad-core ARM Cortex A53
GPU: Mali-G31 OPenGL ES3.2
Memory: 2GB
Flash: 8GB/16GB
WiFi: IEEE 802.11 b/g/n/ac/ax
Bluetooth-Compatible : BT5.0 (only supports connecting to Bluetooth-Compatible remote control, does not support connecting to other Bluetooth-Compatible devices)
Input/Output:
1*HD: Support up to 4K
1*USB: 1*USB2.0
1*Power supply: 5V/2A
Software:
Operating system: Android 14.0
Video: Video decoder
Support video decoding up to 4K@60fps
Support multiple formats:
H.265Main10@L5.1 up to 4K@60fps
VP9 profile 24K@30fps
AVS2 JiZhun 10-bit profile 4K@30fps
H.264 BP/MP/HP@L4.2 up to 4K@30fps
H.263 BP1080p@60fps
Video encoder
H.264 BP/MP/HP
H.264 supports I/P frames and only supports a single reference frame
MJPEG/JPEG baseline
The maximum resolution of H.264 encoding is 16 million pixels (4096 x4096)
H.264 encoding capability: 1080p@60fps
JPEG decoder
Supports IPEG encoding, performance 1080p@60fps
Supports configurable picture resolution
Supports configurable quantization table for Y component Cb
Component and chrome component separately
Support OSD front-end overlap
Support color to gray function
Compatible with HDCP 2.2 and HDCP 1.4
Supports DDc and SCDc
Integrated CEC hardware engine
Video support:
2D video: 4K/1080P/10801/720P/576P/480P/5761/480l, up to 4K@60fps
3D video: 4K/1080P/720P/576P/480P, up to 4K@30fps
Supports RGB/YUV444/YUV422/YUV420 output
Color depth: 8/10 bits
HDR10: Compliant with CTA-861.3 and SMPTE ST 2048 standard
Audio: Support MP3, AAC, WMA, RM, FLAC
Image: HD JPEG, BMP, GIF, PNG, TIF
Language: Multi-language
Product weight: 30g
Product size: 86.20x30.60x13.30mm/3.39x1.2x0.52inch
